Tangents

bounce flash photography & white balance settings

September 19, 2011

bounce flash photography & white balance settings

A question that often comes up, is whether the white balance will change when bouncing flash. The answer is an obvious one – yes, the light will pick up any color cast from a non-white surface. But that is why we need to shoot in RAW. Then the decision about exact White Balance becomes less crucial.

The photograph above, is of Roz, and was taken during the recent flash photography workshops in Dublin, Ireland. Roz was Ireland’s contestant in the 2010 Miss Universe contest, so it was quite a privilege to have her as one of our two workshop models!

The lighting in this image is simplicity itself: on-camera bounce flash, with the black foamie thing as a flag to block the light from the flash directly hitting her. Of course, the ambient light coming in through the window acts as a secondary light, helping with a bit of rim-light there and also in creating background lighting.

In getting the light from my on-camera flash to come in from a pleasing angle – short lighting – I had to bounce the flash off the wooden panelling in the room. This of course made for a far-too-warm white balance:

With this pull-back shot, you can see what the room looked like. For the photo at the top though, I bounced my flash off the wall to my right.

I knew the wooden panelling would make the color balance become very warm. So I guessed a 3700K white balance setting. It turned out to be fairly okay, but I still needed to fine-tune the White Balance as part of my normal RAW workflow for a pleasant color balance. The color of the background shifted as well, but this wasn’t of any concern to me.

As a comparison, here is what my out-of-camera WB (at 3700K) looked like, with what it would’ve looked like as Daylight WB (set on the RAW file via ACR / Bridge)

Therefore my advice about off-color surfaces and bounce flash, is to try and get the WB as close as you can since it does help in judging the image’s exposure from the camera’s preview. But ultimately, don’t sweat it – shoot in RAW, and concentrate on getting great lighting and also, keep the momentum and flow of the photo shoot going. Fussing over exact settings which can be finessed in post-processing, will only slow the photo session down.

camera settings and details:
1/125 @ f3.5 @ 800 ISO
Nikon D3; Nikon 70-200mm f2.8 AF-S VR II (B&H)
Nikon SB-900 (B&H); black foamie thing

photography books by Neil vN

Amazon USA

Amazon UK

newsletter / forum / workshops & seminars

Stay informed of new articles via the monthly newsletter.
Also join us on the Tangents forum for further discussions.

If you need more direct help or instruction on flash photography,
I do present workshops & seminars and also offer individual tutoring sessions.

If you find these articles interesting and of value, then you can help by
using these affiliate links to order equipment & other goodies. Thank you!

26 Comments »

Excellent – once again / as always

Comment by Johan — September 20, 2011 @ 5:27 am
She’d even look great blue :)

Comment by SEAN SHIMMEL — September 20, 2011 @ 7:25 am
I can see why Roz was an Miss Universe entrant. She has a strong presence. Neil brings out the best in people.

Comment by Stephen — September 20, 2011 @ 10:20 am
Love you blog as always, Neil!

One question, I found it tough to get a correct WB afterwards with my RAW. Usually I click on something neutral or white for the WB in post processing but many times it would still give me a colour cast. Do you use a grey card everytime the light changes? Because I certainly cannot do that when shooting in a church event.

Cheers,
Alex

Comment by Alex — September 20, 2011 @ 12:56 pm
Alex, with portraits I start off by clicking on the white of my subject’s eyes … and then I adjust it from there by how the image appears on my screen. It’s more “adjust to taste” than it there is a specific method to it.

Neil vN

Comment by Neil vN — September 20, 2011 @ 1:34 pm
It’s a lovely photo i can imagine you was pretty pleased with it also. Can i ask, do you ever bounce of a large reflector or just always available walls and ceilings?

Comment by simon — September 20, 2011 @ 2:37 pm
Simon, a reflector would be more ideal than the wooden surface. And when there is nothing to bounce your flash off, a reflector is just perfect.

Neil vN

Comment by Neil vN — September 20, 2011 @ 4:35 pm
Like always great work !!!

Do you think using a WhiBal card for the first shot or before/after the shoot (then copy white balance to other pictures) would be helpful for those with limited experience.

Thanks

Comment by daniel — September 20, 2011 @ 6:38 pm
That would work if there was just the single portrait, or if several portraits were taken from one position. But when you change your position, the WB often changes as the surface you’re bouncing off, also change.

Neil vN

Comment by Neil vN — September 20, 2011 @ 9:37 pm
Maybe I’m crazy (or maybe I just need to recalibrate my monitor) but her hair seems a little on the green side to me. Anyone else, or shall I break out the spyder?

Comment by photomatte — September 21, 2011 @ 1:17 am
With the wild swing in color balance between the bounced flash and the daylight (which acts as background light), there is a bit of a turquoise thing happening there on the edges. I can’t say the effect bothers me in the least.

Neil vN

Comment by Neil vN — September 21, 2011 @ 1:22 am
Hi there Neil,

What would be the effect, if any, in a situation like this, if you had gelled the flash?

Comment by Walter — September 21, 2011 @ 1:02 pm
Walter, to correct for the strong color cast, would need a blue gel of some kind. To get an exact value would mean a more rigorous method including using a color temperature meter. That just falls outside the scope of most photo shoots, especially a quickly set up portrait like this.

If the color shift is a problem, then the obvious way out would be to use off-camera flash, and not bounce the flash at all.

Neil vN

Comment by Neil vN — September 21, 2011 @ 10:12 pm
Hi Neil,

Where was your second sb-900 placed that’s listed at the end of the blog post?

Comment by Joe — September 22, 2011 @ 8:07 am
… in my camera bag. ;)
It’s a mistake, copying the text from a similar previous post. I’ve fixed the text now. Thanks.

Neil vN

Comment by Neil vN — September 22, 2011 @ 8:10 am
Thanks Neil, I was hoping you’d address colour cast more thoroughly in one of your posts.

I’ve been seriously trying your technique (BFT and all) and ran into a hitch when I was in a dimly lit private dining room for a special event. The ceiling was of standard height so any part of the ceiling near the bounce area was much brighter than the subjects (I had to shoot wide to include full tables of people at times). If I bounced over my shoulder the light fall off was dramatic – so my subjects were well lit but poorly separated from the dark background. What do you do in such situations while trying to avoid direct flash? I did crank my ISO very high to the limit of what my 7D can really produce nicely which helped but it wasn’t ideal.

Thanks for your input as always.

Comment by Philippe Dame — September 22, 2011 @ 9:09 am
Philippe .. you could try bouncing your flash off a wall to your side, and that way get some light to the background.

But quite often, the only way to get some light in on the background is by using additional lighting. There is only so much we can do with bounced flash since it is a single light source.

Neil vN

Comment by Neil vN — September 22, 2011 @ 11:19 am
Hi Neil

What skin smoothing processing did you use round Roz’s chin/cheekbone area?
Or did you just clone from another section of her face?

Comment by Derek — September 22, 2011 @ 2:48 pm
Derek .. it was just the Healing Tool in Photoshop, and then a slight variation of my usual retouching and post-processing for portraits.

Neil vN

Comment by Neil vN — September 22, 2011 @ 3:00 pm
Hi Neil,

I have tried gelling my flash with 1/2 CTS but sometimes I get a blue color cast or the orange grungy color cast as in the comparison photo on the right. Could it be because I set my camera’s WB to tungsten on the nikon D90?

Comment by Trina Cheney — September 22, 2011 @ 3:12 pm
Trina … the 1/2 CTS gel is best used around 3700K, instead of Tungsten / Incandescent WB. Otherwise your image will have a color cast. But you still need to shoot in RAW to help fix any color shifts because of the color of the bounce surface.

Check here for more on gelling your flash for tungsten.

Neil vN

Comment by Neil vN — September 22, 2011 @ 6:29 pm
Thanks Neil

Comment by Derek — September 23, 2011 @ 4:45 am
Neil, do you have some user presets for WB in your camera? I’ve been pondering this for mine so I have a quick setting for wood interiors. Thanks, Cathy

Comment by Cathy Deschamps — September 26, 2011 @ 12:54 pm
Cathy – two articles on WB settings. (I mostly keep to the camera’s various presets. But I do shoot in RAW and that offers me a lot of flexibility.

- which white balance setting should I use?
- white balance settings – my approach

Neil vN

Comment by Neil vN — September 27, 2011 @ 5:59 am
Once again this new post is really good!

Comment by photographe mariage — September 27, 2011 @ 2:34 pm
I don’t see any green in her hair (color corrected Dell via spyder II).

How about shooting a grey body as a raw backup. I always carry a small 18% grey cloth which will also clean your lens (it is meant to do that as it has micro cleaning fibers).

How about a custom white balance using a Hugo Fong (his cousin) cap over the lens. Fast and it usually works. In this type of lighting, I too prefer raw.

You would get it close this way also.

PERFECT loop lighting on her face. Lovely modified 2/3rds view. Love it.

You usually pick great looking women.

Canon 5d Mk II, 580 exII, Quantum T5d, white/silver reflectors and of course that black thingy.

Comment by Kirk — October 4, 2011 @ 12:07 pm
