October 22, 2012

controlling bright sunlight with direct off-camera flash – (model: Molly K)

Working with Molly K as our model during an individual flash photography workshop in New York, we put in action the thought-process when using flash in very bright light. There’s a specific algorithm that gets us to optimal settings.

But, as usual, there’s more to a final image than just the numerical settings on the camera …

camera settings and decisions

When trying to over-power the sun with flash, the best algorithm is usually:
- maximum flash sync speed,
- lowest ISO,
- find the aperture for your brightest area that you want to expose correctly for,
at that specific shutter speed and ISO.

So that brings us to the central question … what should I be metering for?

Here is the test shot where I decided how I wanted to frame Molly K …

There are three broad areas here to consider in terms of the ambient exposure:
- the bright sky, (which is unevenly bright),
- the shadowed areas of the building on the left,
- the sunlit building on the right.

In this instance I wanted to frame her against the bright sky, and allow the exposure for the sun-lit building to fall where it may. That hot-spot where the sun reflected off a window, was a lucky accident in a few frames.

Metering for the sky, I got:  1/250 @ f8 @ 100 ISO
It made more sense though to get a bit more depth-of-field because of how I composed the shot.
So I settled on:  1/250 @ f11 @ 200 ISO

I wanted more depth of field because of my angle of view. I wanted that low view-point. So low that I couldn’t actually look through the camera’s viewfinder.

I pre-focused on Molly’s hands on her hips … and then held the camera to the ground.

I fired off several sequences of photos, changing the camera’s angle slightly with every shot … just to make sure that I do end up with a few good compositions. My success rate was surprisingly good because the wide-angle view was forgiving of slight framing errors. This is why the reflection of the sun in the windows was a lucky accident in a few frames. I couldn’t actually see it in my viewfinder at the time and make sure I got it every time.

For the off-camera flash portion of the workshop, we had been working with my regular Lastolite EZYBOX 24×24″ softbox (vendor). However, trying to match the bright sky with a speedlite, I knew that a softbox would just eat up too much of the light. Therefore I went with bare, un-diffused off-camera flash.

Bare flash is less forgiving of how you pose your subject and position your light. A softbox on the other hand, is quite forgiving in how you place the light.

The flip-side though, is that with bare flash, you can use simple methods of figuring out the flash exposure:
- you can use the guide number of your flash, or
- use the distance scale of your flash / speedlite / speedlight

The Nikon SB-910 and Canon 600EX-RT (vendor) speedlites have a distance scale on the flash. This allows you to balance that equation for correct manual flash exposure – aperture / ISO / distance / flash power.

Since the aperture and ISO is given for us … and we have our speedlight to manual output, then the distance scale will tell us approximately how far to hold the flash from your subject. Of course, a few test shots will allow you to finesse this for better exposure. I worked with the flash at full output.

And there you have it:  f11 at 200 ISO … for the distance shown in this pull-back shot. The speedlight’s head was zoomed to 28mm, if I recall correctly.

The important step here though, was deciding on a specific background. That’s one of the key elements with effective on-location portraits - what is our background, and how do we want to use it?



video tutorials to help you with flash photography

If you like learning by seeing best, then these video tutorials will help you with understanding flash photography techniques and concepts. While not quite hands-on, this is as close as we can get to personal instruction. Check them these and other video tutorials and online photography workshops.



equipment (or equivalents) used during this photo session:

Oh, the colorful blinged-out look of my lens is because of the lens-skins that I use on my two main lenses.



post-processing the image

Retouching the image at the top, I started with the Healing Tool in Photoshop for any skin blemishes and marks. Then, as part of my usual post-processing workflow, I used two essential Photoshop plug-ins – Shine-Off and Imagenomic Portraiture – as described in this article: Photoshop filters – retouching for portraits. That gives me a basic file that looks good and I can work on a little bit.

Similar to the vintage photo session Sarah R, I used  a home-brew recipe in Radlab, to make the image pop with more contrast and saturation.

For the final image, I did use the Clone Tool and Healing Brush to remove some clutter in the background, such as one of the construction cranes.

And this is how one of my favorite recent images came together.  Oh, the pool of light at Molly’s feet really are from the flash, and not from post-processing.



related articles



help support this website



{ 21 comments. } Add a Comment

1 denton October 22, 2012 at 6:17 am

The flash was not on the camera but held on a stick by an assistant, right?

Reply

2 Neil vN October 22, 2012 at 9:39 am

Yes, the flash was off-camera and was held aloft by someone else. You can see this in the pull-back shot.

Reply

3 sheri j October 22, 2012 at 10:56 am

awesome demonstration :) you rock!

Reply

4 Julian October 22, 2012 at 11:49 am

What “stick” :) was being used to hold the flash? I’ve been looking for a decent one for both small flash and studio strobe.

Reply

5 Neil vN October 22, 2012 at 4:53 pm

Julian .. it could be any monpod really.

I use the Manfrotto 680B monopod, but there are other monopods which might be slightly lighter.

Then I also use a stud to attach the softbox to the monopod.

Reply

6 Jorge Garcia October 23, 2012 at 9:44 am

No the goatee? Great work as usual!

Reply

7 Julian October 23, 2012 at 2:08 pm

Thanks for your reply Neil. Appreciate the response, and most importantly your time on putting these type of things on your blog.

Reply

8 Stephen October 23, 2012 at 10:47 pm

In the shot of you placing the camera to the ground, one can see how bright the day actually was (in the open street area). Using f11 made the sky look like sunset, adding to the photo appeal.

Reply

9 Michael October 23, 2012 at 11:11 pm

Hi Neil, I am learning so much from your blog, thank you.
Quick question – looks like there is some kind of additional device in front of the flash, what is that?

Thanks!
Michael

Reply

10 Trev October 24, 2012 at 12:03 am

Michael,

That’s the speed ring for attaching a soft box, which the flash head pokes through, and Neil merely removed the softbox.

Trev

Reply

11 Michael October 24, 2012 at 7:49 pm

Thanks for the clarification Trev!

Reply

12 Dustin October 25, 2012 at 11:43 am

Hi Trev,

I just follow this website since last month. I have learn a lot as an amateur hobby. I just bought same softbox from B&H through your link. There are two peice of filter cloths in there but Lastolite doesn’t have instruction of how to use the small cloth piece. Do you and Neil even use this small cloth at all to soften the light?

Thanks,

-Dustin

Reply

13 Trev October 26, 2012 at 10:18 am

Hi Dustin,

I presume you mean Neil’s link. :)

Both those cloths are the diffusers, you can use both for more softer light, or just use the one.

Now here is a link to a PDF file from Lastolite site on instructions [this is a small one, and different attachment to speedlite, but principle still the same with diffusers]

Look in the middle column, it’s the 9th item down, click on ‘Ezybox Speedlite’ and you will get a PDF download, just look at that.

I personally only use the larger outer diffuser myself, and don’t know what Neil does, up to you.

Also you can use no diffusers at all if you need the extra power in brighter sunlight, and Neil simply removed the softbox altogether in the above sample.

I use a Quantum and it has a bare bulb with it’s own metal diffuser removed, so when I put it into a softbox [not the Lastolite] it gives a lot of power since it bounces all around the inside of the silver lined softbox with no diffuser panels in place.

Trev.

Reply

14 Neil vN October 26, 2012 at 11:30 am

Dustin, I often use the Lastolite without the inner diffuser. It depends on how bright the available light is, and whether I need a fast recycle time.

So for workshops, I don’t use the inner baffle.

Reply

15 Tilo October 27, 2012 at 4:17 am

wow, great shot — as always!

all the best from Germany, cheers, Tilo

Reply

16 Daniel November 13, 2012 at 12:10 pm

Neil I love your blog, you give away so much information. Thank you so much! Now I just need to get off my butt and find a model to try this stuff.

Reply

17 edy April 2, 2013 at 6:06 am

Hello Neil,
                 a question!
You said that the sb910 flash can read the distance scale ……….. but with off-camera flash and placing the flash off the camera distance scale can not be read.
Right?
How do I regulate me?
How can I calculate the distance scale with off camera flash?
thanks Neil
You are always fantastic and I will follow you every day.
Edy Trigona
Genoa Italy

Reply

18 Neil vN April 2, 2013 at 12:57 pm

Your SB-910 most certainly does give you the distance (for specific power / aperture / ISO) on the display.
You can change the ISO setting in the menu.

Go through this article: tutorial on how to use the GN of your flash.

Reply

19 Michael March 1, 2014 at 12:48 pm

This photo is breathtakingly beautiful! Thanks for showing us how it’s done!

Reply

20 leray June 22, 2014 at 4:45 pm

hi Neil. Love your outside the box suggestions.
My question is what time of the day are these taken?

Reply

21 Neil vN June 25, 2014 at 12:15 am

It was 4pm in the afternoon, in October.

Reply
